| MODEL | NO. | BORE (in.) | BELL (in.) | VALVE(S) | REMARKS | Image |
|---|---|---|---|---|---|---|
| Professional | .450-.462 | Duo Bore |
|
|||
| Super Collegiate | |
|
||||
| Revelation Military | 0.458 | 4 5/8 | Produced: 1941 - 1941 half circle tuning slide crook Aircraft Strut Bell Brace |
.jpg)
|
||
| .442-.462 | 4 13/16 | Produced: 1911 - 1911 Bb/A HP/LP or LP Main Tuning & HP/LP with tight bends in crook H slide: Bb/A Select Z Bell Brace Straight Tuning Brace Stop Rod 2nd Slide angled forward |
|
|||
| 3p 1r | Not documented in catalogs Produced: 1910 - 1910 Bb/A HP/LP or LP 3 Main Slides: Bb-A-Rotary with tight bends in crook H slide: LP adapt on HPs Z Bell Brace Straight Tuning Brace |
|
||||
| Orig | 3p 1r | Produced: 1901 - 1907 Bb/A Rotor |
|
|||
| New Holton | 3p 1r | Produced: 1908 - 1910 .460 bore shown Bb/A HP or LP 3 Main Slides: Bb-A-Rotary with moderately tight bends in crook Curved Bell Brace Curved Tuning Slides 2nd valve tubing angles forward |
|
|||
| .422-.462 | 4 13/16 | Produced: 1912 - 1913 Bb/A HP/LP or LP Main slide Tuning & HP/LP with tight bends in crook H slide: Bb/A Select Z Bell Brace Straight Tuning Brace Stop Rod 2nd Slide angled back |
|
|||
| Quick-change | 3p 1r | Not documented in catalogs Produced: 1913 - 1913 Bb/A HP & LP Main slide Tuning & HP/LP with tight bends in crook Z Bell Brace Straight Tuning Brace Rotor forward of valves |
|
|||
| .442-.462 | 4 1/2 | Produced: 1919 - 1919 Bb/A HP/LP or LP Main slide Bb/A & HP/LP with tight bends in crook H slide: Tuning Z Bell Brace Straight Tuning Brace Stop Rod Slightly longer first Elkhorn horn |
|
|||
| Revelation | .460 | 4 1/2 | Produced: 1920 - 1921 Bb/A tight bends in Main tuning crook Z Bell Brace Top Mount Stop Rod Original Revelation One piece Bell |
|
||
| .442-.462 | 4 1/2 | Produced: 1920 - 1921 Bb/A HP/LP or LP Main Slide: Bb/A & HP/LP tight bends in Main tuning crook H slide: Tuning Z Bell Brace Straight Tuning Brace Stop Rod Both Sides Microtuner to hold when front thrown to A ins in Brace |
|
|||
| Revelation | .442.460 | 4 1/2 | Produced: 1922 - 1931 Bb/A HP/LP or LP tight bends in Main tuning crook Z & Offset front Bell Brace Reversed Leadpipe Top Mount Stop Rod Long tapered Leadpipe One piece Bell |
|
||
| Revelation Jazz Hound | .423 | 3 15/16 | Produced: 1925 - 1931 Bb/A moderately tight bends in Tuning Slide crook Z & Offset front Bell Brace Reversed Leadpipe Top Mount Stop Rod |
|
||
| Galaxy | 0.459 | 4 7/8 | Produced: 1961 - 1967 moderately tight bends in Tuning Slide crook Z Bell Brace Straight Tuning Brace German Silver Bell German Silver leadpipe Stop Rod (3rd) |
|
||
| .442-.462 | 4 13/16 | Bb/A HP/LP or LP 2 Main slide Tuning & HP/LP with tight bends in crook H slide: tuning Z Bell Brace Straight Tuning Brace microtuner Produced: 1914 - 1918 |
|
|||
| Cannon | .473 | 4 13/16 | Bb/A
moderately tight bends in Tuning Slide Crooks Offset Bell Brace Reversed Leadpipe Top Mount Stop Rod Produced: 1925 - 1928 |
|
||
| .460 | 4 1/2 | Bb/A HP/LP, or LP
Stop Rod , Microtuner
Straight wire tuning brace
Z Bell Brace
Dual Tuning Radius
Esbach nested tuning slides Produced: 1922 - 1926 |
|
|||
| T101 | .459 | Designed to compete with Conn Connstellation
Trigger on First Produced: 1968 - 1981 |
||||
| T103 | Patterened on T-101 with bore differences Trigger on first Produced: 1968 - 1981 |
|||||
| T104 | Seemingly same as T-102, but must have had some difference Produced: 1968 - 2000 |
|||||
| Symphony | 21 | Eb |
|
|||
| Symphony | 23 | D |
|
|||
| Revelation | 30 | 0.458 | 4 1/2 | Produced: 1932 - 1937 00 1/2 Bore Revelation New Professional Trumpet in lacquer finish Bb/A moderately tight bends in Tuning Slide crook Curved X Offset Bell Brace Reversed Leadpipe Top Mount Stop Rod |
|
|
| Professional | 30 | .459 | 4.5 | Revelation New Professional Trumpet in silverplate finish
00-1/2 bore
Bb/A
moderately tight bends in Tuning Slide crook
Curved X Offset Bell Brace
Reversed Leadpipe
Top Mount Stop Rod
Catalog suggests .461 bore, measures .459 Produced: 1932 - 1936 |
|
|
| Streamline | 32 | 0.453 | 4 13/16 | Bottom sprung Ideal/Collegiate Valves Produced: 1932 - 1935 Bb/A D shaped tuning slide crook Curved X Offset Bell Brace Reversed Leadpipe Top Mount Stop Rod Catalog suggests .461 bore, measures .453 |
|
|
| Resotone | 34 | 0.461 | 4 5/8 | Produced: 1937 - 1938 Bb/A moderately tight bends in Tuning Slide crook Curved X Offset Bell Brace Reversed Leadpipe Top Mount Stop Rod Elongated Mpc Receiver Two Piece Bell |
|
|
| Galaxy | 401 | .459 | |
|||
| Ideal | 405 | Produced: 1934 - 1937 |
|
|||
| Revelation | 42 | .423 | 4.5 | 00 Bore
Revelation New Professioal
Bb/A
Moderately tight bends in tuning
Curved X Offset Bell Brace
Reversed Leadpipe
Top Mount Stop Rod Produced: 1932 - 1937 |
||
| Professional | 42 | .423 | 4.5 | "Revelation New Professional Trumpet" in silverplate finish
00 bore
Bb/A
moderately tight bends in Tuning Slide crook
Curved X Offset Bell Brace
Reversed Leadpipe
Top Mount Stop Rod
Produced: 1932 - 1937 |
||
| Deluxe | 45 | 0.458 | 4 13/16 | Produced: 1945 - 1962 tight bends in tuning slide crook Aircraft Strut Bell Brace Straight Tuning Brace Rose Brass Bell Stop Rod (3rd) |
|
|
| Revelation | 45 | 0.458 | 4 13/16 | Produced: 1945 - 1962 half circle tuning slide crook Z Bell Brace Reversed Leadpipe Stop Rod (3rd) |
|
|
| Revelation | 45 | .458 | 4.75 | half circle tuning slide crook
Z Bell Brace
Reversed Leadpipe
Top Mount Stop Rod
One piece Bell
Produced: 1939 - 1941 |
||
| Professional | 46 | .442 | 4.5 | Revelation New Professional
00-1/4 bore
Bb/A
Moderately tight bends in tuning slide crook
Curved X Offset Bell Brace
Reversed Lead pipe
Top Mount Stop Rod
Produced: 1932 - 1937 |
||
| Revelation | 46 | .442 | 4.5 | Revelation New Professional Trumpet in lacquer finish
00-1/4 bore
Bb/A
moderately tight bends in Tuning Slide crook
Curved X Offset Bell Brace
Reversed Leadpipe
Top Mount Stop Rod
|
||
| Symphony | 47 | 0.458 | 5 | 1 piece Bell
moderately tight bends in Tuning Slide crook
Z Bell Brace Straight Tuning Brace Rose Brass Bell Stop Rod (3rd) Opt 1st slide trigger Produced: 1949 - 1961 Renamed by 1956 to B47 |
|
|
| Deluxe | 48 | 0.458 | 4 13/16 | Produced: 1945 - 1962 tight bends in tuning slide crook Aircraft Strut Bell Brace Straight Tuning Brace Rose Brass Bell Brass/Nickel leadpipe Stop Rod (3rd) Some with german Silver leadpipe |
|
|
| Revelation | 48 | 0.458 | 4 13/16 | Produced: 1945 - 1962 half circle tuning slide crook Z Bell Brace Reversed Leadpipe Stop Rod (3rd) |
|
|
| Revelation | 48 | .458 | 4 3/4 | Produced: 1939 - 1941 half circle tuning slide crook Z Bell Brace Reversed Leadpipe Top Mount Stop Rod One piece Bell |
|
|
| Llewellyn | 48 | 0.460/.473 | 4 13/16 | Produced: 1928 - 1931 Bb/A or Bb moderately tight bends in Tuning Slide crook Offset Bell Brace Z (& Offset 1924-41) Bell Brace Reversed Leadpipe Top Mount Stop Rod (1925-41) Canon 1925-8 Llewellyn 1928-31 |
|
|
| Stratodyne | 49 | 0.459 | 4 13/16 | Produced: 1948 - 1961 Renamed by 1963 to B49 moderately tight bends in Tuning Slide crook Aircraft Strut Bell Brace Straight Tuning Brace lightweight Rose Brass Bell Brass(yellow in 40s)/Nickel leadpipe Stop Rod (3rd) Lightweight Bell Opt 1st slide trigger |
|
|
| 50 | M or L | 5 | Later designated as B10X, T10X and 104 Produced: 1962 - 1965 moderately tight bends in Tuning Slide crook Z Bell Brace Straight Tuning Brace Rose Brass Bell Stop Rod (3rd) |
|
||
| Symphony | 50 | .473 | 4 13/16 | Bb/A
D shaped tuning slide crook
Curved X Offset Bell Brace
Reversed Leadpipe
Top Mount Stop Rod
Produced: 1931 - 1936 |
|
|
| Ambassador | 506 | |
||||
| Large Bore | 51LB/LB-51 | 0.464 | 4.75 | Produced: 1948 - 1965 tight bends in tuning slide crook Aircraft Strut Bell Brace Straight Tuning Brace Rose Brass Bell Stop Rod (3rd) |
|
|
| Symphony | 52 | 0.459 | C or D (built to order in the early and mid 1950s) based on 47 Symphony |
|
||
| Symphony | 53 | Bb/C 2 slides (early 1950s) |
|
|||
| Revelation | 56 | Eb Alto |
|
|||
| Symphony/Revelation | 58 | 6 | Bass Produced: 1949 - 1965 |
|
||
| B47 | .458 | 5 | 47 renamed by Leblanc
1 piece Ball Produced: 1956 - 1965 |
|
||
| B49 | .459 | 4 13/16 | 49 Stratodyne renamed by Leblanc
Lightweight 1pc Rose Brass Bell Produced: 1963 - 1965 |
|||
| G44 | |
|||||
| Maynard Ferguson | LT302 | .468 | |
|||
| Dave Stahl | ST100 | .465 | In the late 70s, the ST-100 was dubbed the “Dave Stahl Trumpet†|
|
||
| ST200 | 0.462 | 4.5 | |
|
||
| Maynard Ferguson | ST301 | .468 | |
|||
| Maynard Ferguson | ST302 | 0.468 | 5 | |
||
| MF Firebird | ST303 | 0.468 | 5 | Tilt Bell |
||
| ST304 | .465 | |
|
|||
| MF Banana | ST305 | 0.484 | 5 | Tilt Bell |
||
| ST306 | .468 | ST-302 with T101 valve block |
||||
| ST307 | .468 | Reversed leadpipe, Circle main crook |
||||
| ST308 | .459 | Reversed leadpipe, circular main crook |
||||
| Al Hirt Special | ST500 | 0.46 | 4.75 | |
|
|
| Maynard Ferguson | ST550 | .460 | |
|||
| ST747 | |
|
||||
| Symphony | T-100 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-100- Symphony trumpet 1968-81 Produced: 1968 - 1981 |
|
|||
| Symphony | T-100X | Adjustable receiver allows for player setting of gap Produced: 1981 - 0 |
|
|||
| T101 | .459 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-101- 1982-2008 a direct copy of an Elkhart Bach 37 Produced: 1981 - 1990 |
|
|||
| T101 | .459 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
Produced: 1990 - 2008 |
|
|||
| T102 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-102 1982-200 ? Is a T-101 with a copy of a Bach 43 bell Produced: 1982 - 2000 |
|||||
| T102 | .465 | moderately tight bends in Tuning Slide crook Z Bell Brace Stop Rod (3rd) Trigger on first Produced: 1968 - 1981 |
||||
| T103 | .459 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-103 1982-200? Is a T-101 with a copy of a Bach 72 bell Produced: 1982 - 2000 |
||||
| T104 | .459 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-104- 1982-200 ? Is the former T102 from 68/69 to 81 Produced: 1982 - 2000 |
||||
| T105 | .459 | moderately tight bends in Tuning Slide crook Z Bell Brace Double Straight Tuning Brace Stop Rod (3rd)
T-105-also sold as LT-101 - 198? - 2008 is a 101 lightweight version Produced: 1982 - 2008 |
|
|||
| T303 | |
|
||||
| Heriot | T505/ST505? | |
|
